The growing number of connected personal and IoT devices has led to an overall increase in network density that is pushing the limits of the current WiFi standard. The latest WiFi 6(802.11ax) standard provides future-proof technologies, higher network efficiency, faster WiFi speeds, greater coverage and improved battery life for connected devices, providing a significantly better networking experience for users Read more
| Network Standard | IEEE 802.11a |
| IEEE 802.11b | |
| IEEE 802.11g | |
| WiFi 4 (802.11n) | |
| WiFi 5 (802.11ac) | |
| WiFi 6 (802.11ax) | |
| IPv4 | |
| IPv6 | |
| Product Segment | AX1800 ultimate AX performance : 1201 Mbps+ 574 Mbps |
| AX technology | Yes |
| Data Rate | 802.11a : up to 54 Mbps |
| 802.11b : up to 11 Mbps | |
| 802.11g : up to 54 Mbps | |
| WiFi 4 (802.11n) : up to 300 Mbps | |
| WiFi 5 (802.11ac) : up to 867 Mbps | |
| WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps | |
| WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps | |
| Antenna | Ex-antennas*4 |
| Transmit/Receive | 2.4GHz 2×2 |
| 5GHz 2×2 | |
| Processor | Dual-core (4 VPE) |
| Memory | 128 MB Flash |
| 256 MB RAM | |
| Boosts speed | OFDMA (Orthogonal Frequency Division Multiple Access) |
| Beamforming: standard-based and universal | |
| 1024-QAM high data rate | |
| 20/40/80 MHz bandwidth | |
| Operating Frequency | 2.4G Hz / 5 GHz |
| Ports | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3,USB Port x1 |
| Button | WPS Button, Reset Button, Power Switch |
| LED Indicator | Power x 1 |
| 2.4G x 1 | |
| 5G x 1 | |
| LAN x 3 | |
| WAN x 1 | |
| USBX1 | |
| Power Supply | AC Input : 100V~240V(50~60Hz) |
| DC Output : 12 V with max. 1.5A current | |
| AC Input : 110V~240V(50~60Hz) | |
| DC Output : 12 V with max. 1.5A current | |
| Package content | RT-AX53U |
| RJ45 x1 | |
| Adapter x1 | |
| QSG x1 | |
| Warranty Card x1 | |
| Product Weight (g) | 346g |
| AiMesh | AiMesh |
| Primary AiMesh router | |
| AiMesh node | |
| Router APP | ASUS Router APP |
| Alexa | Support Alexa skill |
| AiProtection | AiProtection Classic |
| Malicious site blocking | |
| Infected Device Prevention and Blocking | |
| Parental Control | Parental Control |
| Parental Control Customized Internet schedule | |
| Traffic Control | Bandwidth limiter |
| Traditional QoS | |
| Traffic Monitor | |
| Real-time traffic monitor | |
| Wired Traffic Monitor | |
| Wireless Traffic Monitor | |
| Wireless | IPv6 |
| Wi-Fi Encryption : Open system, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA3-Personal | |
| UTF-8 SSID | |
| Guest Network | |
| WPS | |
| WiFi MAC address filter | |
| Wireless scheduler | |
| Airtime fairness | |
| RADIUS Client | |
| Universal beamforming | |
| Explicit beamforming | |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP |
| Dual WAN | |
| 3G/4G LTE dongle | |
| Port triggering | |
| DMZ | |
| DDNS | |
| Let’s Encrypt | |
| LAN | DHCP Server |
| IPTV | |
| Manually assign IP address | |
| VPN | VPN Client L2TP |
| VPN Client OVPN | |
| VPN Client PPTP | |
| VPN Server IPSec | |
| VPN Server OVPN | |
| VPN Server PPTP | |
| USB application | |
| 3G/4G LTE dongle | |
| HDD hibernation | |
| Safely Remove disk | |
| Download master | |
| AiDisk | |
| Media Server | |
| Samba Server | |
| FTP Server | |
| Shared Folder privileges | |
| Administration | Operating mode : Access Point, Media Bridge, Repeater, Router |
| Operating system : ASUSWRT | |
| Free OS upgrade | |
| Firewall | |
| SSH | |
| Wake on LAN (WOL) | |
| Configuration backup and restore | |
| Diagnosis tools | |
| Feedback system |
