ASUS ROG Rapture GT-AXE16000 Quad-Band WiFi 6E (802.11ax) Gaming Router, new 6 GHz band, dual 10G ports, 2.5G WAN port, dual WAN, AiMesh support, VPN Fusion, Triple-level game acceleration and free network security... Read more
Product Details
Experience Ultimate Connectivity
With four frequency bands available, you can dedicate each band to different devices for faster and smoother WiFi connections. It also gives you even more flexible options for connecting ASUS AiMesh-compatible routers as mesh nodes if you want to create a whole-home mesh system.
Built as the Ultimate AiMesh Router
By default, one of GT-AXE16000's two 5 GHz bands is used as a dedicated backhaul connection to the central router, so your devices still have full tri-band access to the 2.4 GHz band, the second 5GHz band and the 6 GHz band.
Built as the Ultimate AiMesh Router
Alternatively, with WiFi 6E AiMesh nodes you can configure a 6 GHz backhaul connection, providing fast and interference-free transmission between nodes for an optimized mesh experience
WiFi 6E - 6 GHz Band
WiFi 6E gives you up to seven* additional high-speed 160 MHz channels, for multi-gigabit speeds with stable and consistent connections. It dramatically increases network capacity while reducing bandwidth congestion, delivering higher performance for every WiFi 6E device.
Customize your WAN
Multi-WAN usage is increasingly popular, and it's great for those who need unstoppable internet. With one 2.5 Gbps WAN port, two 10 Gbps ports and four 1 Gbps ports that can also be configured as WAN ports, you don't have to rely on a single ISP. With dual internet connections from two different ISPs, even if one fails, you'll still have access to the other.
Dual 10 Gbps Ports
For power users with 10GBase-Tenabled PCs, servers or NAS devices, the dual 10 Gbps ports are perfect. These are more convenient than simply combining multiple gigabit Ethernet ports, and help increase your available bandwidth to avoid data bottlenecks for your whole network.
Built for the Ultimate Speed
ROG Rapture GT-AXE16000 is powered by the latest 2.0 GHz quad-core 64-bit CPU and WiFi chipsets, giving it the performance to handle even the most demanding gaming networks. Maximum network throughput is increased by up to 18%* for lightning-fast responsiveness, accelerated data transfers and an optimized gaming experience.
*Disclaimer: In comparison with the former WiFi 6 platform.
Built for the Ultimate Coverage
ASUS RangeBoost Plus is the latest, most powerful version of our renowned RangeBoost technology, which can improve coverage and WiFi performance significantly compared to other models without RangeBoost. By using next-gen flagship Broadcom WiFi chipsets with the exclusive ASUS RF technology, RangeBoost Plus leverages multiple upgraded ASUS features that improve WiFi signal range and overall coverage by up to 38%*.
*Measured using a WiFi 6 client connected at 200 Mbps to a WiFi 6 router with RangeBoost Plus, and compared to the same WiFi 6 client connected at 200 Mbps to a WiFi 5 router without RangeBoost Plus.
To Infinity and Beyond
For the ultimate style, ROG Rapture GT-AXE16000 has an infinity mirror on the top of the case that adds a unique touch to the multiple Aura RGB lighting effects. GT-AXE16000 shows your true style while gaming!
Brand | ASUS |
---|---|
Model | GT-AXE16000 |
Standards | Wi-Fi 6E (802.11ax) Wi-Fi 6 (802.11ax) Backwards compatible with 802.11a/b/g/n/ac Wi-Fi |
---|---|
Wireless Standard | IEEE 802.11a / IEEE 802.11ac / IEEE 802.11ax / IEEE 802.11b / IEEE 802.11g / IEEE 802.11n |
WAN Ports | 1 x 2.5G |
LAN Ports | 4 x RJ45 for Gigabits BaseT for LAN 2 x RJ45 for 10G BaseT for WAN/LAN |
LEDs | 1 x Power 1 x 2.4G 1 x 5GHz-1 1 x 5GHz-2 1 x 6G 1 x 10GE Port 1 x LAN 1 x WAN |
Buttons | WPS Button, WPS Button, Reset Button, Power Switch |
Wireless Data Rates | 2.4GHz AX: 4×4 (Tx/Rx) 1024 QAM 20/40MHz, up to 1148Mbps 5G-1Hz AX: 4×4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps 5G-2Hz AX: 4×4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps 6GHz AX: 4×4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps |
Frequency Band | 2.4 GHz / 5 GHz / 5 GHz / 6 GHz |
Antenna | External antenna x 8 (non-detachable) |
VPN support | VPN Client L2PT : Yes VPN Client OVPN : Yes VPN Client PPTP : Yes VPN Server IPSec : Yes VPN Server OVPN : Yes VPN Server PPTP : Yes VPN Fusion : Yes |
Processor | 2.0 GHz quad-core processor |
Features | World’s first quad-band WiFi 6E gaming router – Ultrafast WiFi 6E (802.11ax) quad-band WiFi router boosts speeds up to 16000 Mbps New 6 GHz frequency band – Wider channels and higher capacity delivers higher performance, lower latency, and less interference. Expanded coverage – The exclusive ASUS RangeBoost Plus improves signal range and overall coverage. Flexible AiMesh configuration – Dedicated 5 GHz or 6 GHz backhaul using ASUS AiMesh routers for more flexible device options. Dual 10G ports – Enjoy up to 10X-faster data-transfer speeds for bandwidth-demanding tasks with two 10 Gbps WAN/LAN ports. 2.5G WAN port – 2.5 Gbps port prioritizes all network traffic, and unlocks the full potential of WiFi 6. Triple-level game acceleration – Accelerate game traffic every step of the way – from device to game server. |
---|
Package Contents | GT-AXE16000 WiFi Gaming Router RJ-45 Cable Power Adapter Quick Start Guide Warranty Card |
---|
