Product Details

Next-Gen Ready - ATX 3.0 COMPLIANT

CORE REACTOR II series power supply units meet Intel ATX 3.0 design guide specifications and feature a 12VHPWR connector. By upgrading to an ATX 3.0-compliant power supply, you'll be fully equipped for the upcoming wave of high-performance components. A must for the modern gamer, creator, or AI developer. Stay ahead of the curve by upgrading to an ATX 3.0 PSU, the new standard in PC hardware.

Certified GOLD Efficiency

CORE REACTOR II units recieved 80 PLUS GOLD certifications for efficiency, achieving up to 91.40% (115V) efficiency at 50% load. It comes in 1200W, 1000W,  850W, 750W, and 650W models for varying user needs and scenarios. It's the perfect PSU for mid-to-high level components, including the latest CPUs and GPUs.

Intelligent Fan-Curve Design

The intelligent fan curve ensures quiet operation, even under full power load. By starting the fan at a low RPM, fan performance is both enhanced and extended, thereby increasing the power supply unit's lifespan.

Premium all 105°C Japanese Capacitors

CORE REACTOR II features top-tier 105°C Japanese capacitors, ensuring exceptional stability and reliability of the PSU for many years of dependable performance.

XPG Cybercore II 1000W 80 Plus Platinum Fully Modular Power Supply Price in Pakistan

Dimensions (L x W x H)

• 160 x 150 x 86mm

Cybenetics Rating

• PLATINUM

80 Plus Rating

• PLATINUM

ATX Version

• ATX 3.0

Protections

• OCP | OVP | OPP | OTP | UVP | SCP | NLO | SIP

Certification

• CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Mark | NOM | BSMI | UKCA | EAC | CCC | RCM

PFC

• > 0.99

Input Voltage

• 100-240V

Input Current

• (1)1300W：15A
• (2)1000W：13A

Input Frequency

• (1)1300W：50-60Hz
• (2)1000W：50-60Hz

DC Output Voltage

• +5V | +3.3V | +12V | -12V | +5Vsb

Total Output

• (1) 1300W
• (2) 1600W

Power Excursion

• 1000W: 2000W (*up to 200% of the PSU’s rated power for 100μs)
• 1300W: 2600W (*up to 200% of the PSU’s rated power for 100μs)

Operating Temperature

• 50°C

Fan Size

• 120mm

Fan Bearing

• Double Ball Bearing

Fan Speed

• 2,150 RPM

MTBF

• 125,000 hours @ 25°C

ATX 24 Pin Connector

• 1300W：1
• 1000W：1

EPS 8 Pin Connector

• 1300W：2
• 1000W：2

PCI-E 6+2 Pin Connector

• 1300W：10
• 1000W：6

Molex 4 Pin Connector

• 1300W：8
• 1000W：4

12VHPWR (12 + 4) Connector (600W)

• 1

SATA Connector

• 1300W：12
• 1000W：8

Floppy 4 Pin Connector

• 1300W：2
• 1000W：1

Weight

• 1000W：
  Product+cables：1.96kg+1.35kg (4.32lb+3.0lb) ±5%
  with Package：4.13kg (9.1lb) ±5%
• 1300W：
  Product+cables：2kg+1.94kg (4.4lb+4.2lb) ±5%
  with Package：4.6kg (10.1lb) ±5%
